| Frame |
Aluminum Optimum G04 140mm BB Standard: BSA, 68mm, threaded |
|---|---|
| Fork |
RockShox Revelation RC Debonair 150 | 1T | 42 Offset |
| Rear Shock |
RockShox SuperDeluxe Select R Db. Trunnion | 2T |185x52.5 |
| Bottom Bracket |
Shimano BB52 | BSA | 68/73mm |
| Headset |
FSA Orbit | 1.5 | Zero Stack |
| Stem |
V2 Pro | B:35mm | L:50mm | 0° |
| Handlebar |
V2 Pro | B:35mm | R:15mm | W:780mm |
| Saddle |
SDG FLY MTN |
| Seatpost |
TranzX | 34.9mm | 1x Lever |
| Grips |
Devinci Performance | w/lock-on |
| Rear Derailleur |
Shimano Deore M6100 | 12s |
|---|---|
| Crank |
Shimano Deore M6130 | 32T | Superboost 157 |
| Shifters |
Shimano Deore M6100 | 12s | I-spec EV |
| Cassette |
Shimano M6100 | 12s | 10-51T | Microspline |
| Chain |
Shimano Deore M6100 | 12s |
| Brakes |
Shimano Deore M4100/MT420 | 4 Pistons |
| Rims |
V2 Comp | 36mm inner | TR |
|---|---|
| Spokes |
Sapim Stainless 14G w/Nylok |
| Front Hub |
Novatec D791SB-B15 | 6bolts | TA 15x110mm |
| Rear Hub |
Novatec DH92SB-MS | 6bolts | TA 12x157mm | Microspline |
| Tires |
Maxxis Minion DHF | 29x2.5wt | 3C EXO TR |
| Disk Rotors |
Shimano RT66 | 203mm |
