Light, lively Split-Pivot Django brings unstoppable stoke to a tangle of trail types. This capable short-travel machine shines on climbs, while bringing adept handling to gnarled, technical turf. Superboost 157 rear spacing combined with 29x2.6 tire clearance accentuate its punchy, aggressive powers on rolling terrain. Relocated adjustable geo flip chips mean less moving parts and simple on-the-fly adjustability. And threaded BBs make for easy maintenance, while molded chainstay and downtube protection helps buck rocks and loose debris. Jump on the fun-hogging Django 29 today and find your happy place — everywhere you ride.
FRAME Aluminum Optimum G04 120mm
HEADSET FSA Orbit | 1.5 | Zero Stack
SEAT CLAMP Alloy CNC | 34.9mm
SUSPENSION FORK RockShox Revelation RC DebonAir 140 | 2T | 42 Offset
REAR SHOCK Rockshox Deluxe Select+ RL Debonair | 3T | 190x45
HANDLEBAR V2 Pro | B:35mm | R:15mm | W:780mm
STEM V2 Pro | B:35mm | L:50mm | 0°
SADDLE SDG FLY MTN
SEATPOST TranzX Dropper | 31.6mm | 1x Lever
GRIPS Devinci Performance | w/lock-on
FRONT BRAKE Shimano Deore M4100/MT420 | 4 Pistons
REAR BRAKE Shimano Deore M4100/MT420 | 4 Pistons
FRONT ROTOR Shimano RT66 | 203mm
REAR ROTOR Shimano RT66 | 180mm
REAR DERAILLEUR Shimano Deore M6100 | 12s
REAR SHIFTER Shimano Deore M6100 | 12s | I-spec EV
CRANKSET Shimano Deore M6130 | 32T | Superboost 157
BOTTOM BRACKET Shimano BB52 | BSA | 68/73mm
CASSETTE Shimano M6100 | 12s | 10-51T | Microspline
CHAIN Shimano Deore M6100 | 12s
FRONT RIM V2 Comp | 29mm inner | TR
FRONT HUB Novatec D791SB-B15 | 6bolts | TA 15x110mm
REAR RIM V2 Comp | 29mm inner | TR
REAR HUB Novatec DH92SB-MS | 6bolts | TA 12x157mm | Microspline
SPOKES Sapim Stainless 14G w/Nylok
FRONT TIRE Maxxis Minion DHF | 29x2.5wt | 3C EXO TR
REAR TIRE Maxxis Aggressor | 29x2.5wt | EXO TR
